PIPE & FITTING SYSTEMS
SDR 11 ( STANDARD DIMENSION RATIO ) WATER 200 PSI , GAS * ( WORKING PRESSURE AT 73.4 ° F ) Water - MOP 200 PSI , Gas *
Electrofusion IPS Tapping Tees
Nominal Diameter
Code da da1 ( OD ) ( OD1 ) s z L1 L2 L3 L4 d3 h b SW t t1
in in in in in in in in in in in in in in in lbs 2 “ / ½ “ CTS RI-51.278.0250.12 2 0.5 0.10 2.24 4.72 3.39 4.02 4.69 1.02 6.67 3.90 0.39 2.34 5.43 1.18
2 “ / 1 “ CTS RI-51.278.0201.12 2 1.0 0.12 2.24 5.12 3.62 4.02 4.69 1.02 6.67 3.90 0.39 2.34 5.43 1.21
Weight
2 “ / ¾ “ IPS RI-51.278.0275.11 2 0.75 0.09 2.24 5.12 3.62 4.02 4.69 1.02 6.67 3.90 0.39 2.34 5.43 1.20
2 “ / 1 “ IPS RI-51.278.0201.11 2 1.0 0.12 2.24 5.12 3.62 4.02 4.69 1.02 6.67 3.90 0.39 2.34 5.43 1.21
3 “ / ½ “ CTS RI-51.278.0350.12 3 0.5 0.10 2.64 4.92 3.39 4.06 5.12 1.26 7.74 5.04 0.67 2.87 5.98 1.62
3 “ / 1 “ CTS RI-51.278.0301.12 3 1.0 0.12 2.64 5.12 3.62 4.06 5.12 1.26 7.74 5.04 0.67 2.87 5.98 1.64
3 “ / ¾ “ IPS RI-51.278.0375.11 3 0.75 0.09 2.64 5.12 3.62 4.06 5.12 1.26 7.74 5.04 0.67 2.87 5.98 1.63
3 “ / 1 “ IPS RI-51.278.0301.11 3 1.0 0.12 2.64 5.12 3.62 4.06 5.12 1.26 7.74 5.04 0.67 2.87 5.98 1.65
• Molded from : PE 100 / PE 4710
• Color : Black
• Specification : ASTM D2513 / F1055 , AWWA C906 , NSF 61
• Sealed brass punch assembly .
• Fixing tab for easy installation .
• Permanent under saddle .
4 “ / ½ “ CTS |
RI-51.278.0450.12 |
4 |
0.5
0.10 2.99 4.92 3.39 4.06 5.12 1.26 8.13 5.87 0.67 3.27 5.98 1.71
|
4 “ / 1 “ CTS |
RI-51.278.0401.12 |
4 |
1.0
0.12 2.99 5.12 3.62 4.06 5.12 1.26 8.13 5.87 0.67 3.27 5.98 1.74
|
4 “ / ¾ “ IPS |
RI-51.278.0475.11 |
4 |
0.75 0.09 2.99 5.12 3.62 4.06 5.12 1.26 8.13 5.87 0.67 3.27 5.98 1.72 |
4 “ / 1 “ IPS |
RI-51.278.0401.11 |
4 |
1.0
0.12 2.99 5.12 3.62 4.06 5.12 1.26 8.13 5.87 0.67 3.27 5.98 1.74
|
6 “ / ½ “ CTS |
RI-51.278.0650.12 |
6 |
0.5
0.10 3.90 4.92 3.39 4.06 5.16 1.26 9.11 8.03 0.67 4.25 5.98 1.28
|
6 “ / 1 “ CTS |
RI-51.278.0601.12 |
6 |
1.0
0.12 3.90 5.12 3.62 4.06 5.16 1.26 9.11 8.03 0.67 4.25 5.98 1.90
|
6 “ / ¾ “ IPS |
RI-51.278.0675.11 |
6 |
0.75 0.09 3.90 5.12 3.62 4.06 5.16 1.26 9.11 8.03 0.67 4.25 5.98 1.89 |
6 “ / 1 “ IPS |
RI-51.278.0601.11 |
6 |
1.0
0.12 3.90 5.12 3.62 4.06 5.16 1.26 9.11 8.03 0.67 4.25 5.98 1.90
|
Notes : 1 . All dimensions shown are nominal and subject to manufacturing tolerance OD and minimum wall are determined in accordance with ASTM standards . Drawing shown is an approximation only . 2 . Fittings are marked to meet the applicable standards .
* The maximum pressure for gas applications should be calculated based on the applicable local and federal regulations .
